Alnico V magnets are used for both the P-90 and humbucker to deliver a clear strumming tone with good projection plus a tight sound that doesn't get buried in the ensemble.
A coil tap function on the rear humbucker delivers a delivers a wide range of tonal possibilities, from hard distortion to an edgy single coil tone. A switch in the tone knob allows quick switching between humbucker and single coil tone.
The heavy block type saddle delivers rich sustain and deep tone.
Like the top-end PACIFICA models, the rear pickup is mounted directly to the body. This configuration captures body resonance, delivering greater dynamic tone rather than pickguard mounting.
1 : 3P Pickup Selector
2 : Master Volume (Push-Pull Switch)
3 : Master Tone
Construction | Bolt-On | |
---|---|---|
Scale Length | 25 1/2" (648 mm) | |
Fingerboard | Rosewood | |
Radius | 13 3/4" (350mm) | |
Frets | 22 | |
Body | Alder | |
Neck | Maple | |
Tuners | Grover Locking Tuner | |
Bridge | Hardtail Bridge | |
Pickups | P-90 (Alnico V), Humbucker (Alnico V) | |
Pickup Switch | 3 position lever | |
Controls | Master Volume, Master Tone (Push-Pull Coil Split) |
